Dripping bathroom fan likely roof related

Question: On several occasions, during and after heavy rains, I have noticed water dripping from a bathroom fan housing. It is usually around one or two cups. However, on one occasion of heavy rain, it didn’t leak. A roofer checked the shingles and pronounced everything OK. He attributed the dripping to extreme humidity and condensation, due to last year’s exceptional humidity.

I have lived here 40-plus years and haven’t experienced this before. The roof was replaced six years ago. The ceiling fan in the bathroom is not used because it has not been working for a long, long time. The dehumidifier in my basement is set to 35 per cent RH. There has been no increase in showers or other sources of humidity in the home. ls it possible that last summer was exceptionally humid and is responsible for the leak, or should I get it checked again? I am hesitant to go up in the attic due to vermiculite covered with fibreglass insulation. I would appreciate your advice before getting another inspection.

Thanks, Larry Semenko

Answer: Moisture intrusion from the ceilings, during or after heavy rains, are almost always from something on the roof leaking. Getting an experienced roofer to identify the point of entry, perhaps with a garden hose water test, will be the key to preventing future leakage in your bathroom.

I have written dozens of times about moisture intrusion at ceilings, often being caused by condensation in attics. While I would agree with your roofer that leaks are often misdiagnosed as roofing issues, when attic moisture is the culprit, that is not likely the case in your home. The main difference between that and a roof leak is the time at which each is occurring. Ceiling moisture issues that occur in the warmer seasons, especially at the same time as it is raining, are from precipitation gaining entry through the exterior.

When water is seen dripping from the ceiling during a steady rain, it is not caused by condensation. Even in your bathroom, where the moisture is leaking through an old ceiling fan, there would not be enough of a temperature drop to cause the warm air inside the attic or fan ducting to significantly condense. Even in extreme conditions, where the humidity is almost 100 per cent on a very hot day, it is doubtful the air inside the attic would cool enough after it started raining, to form more than a little bit of sweat on any cold surfaces. While this could certainly happen inside a metal bathroom exhaust fan duct, it would never amount to enough water for more than a few drops.

If you had told me that the dripping occurred in early spring, late fall or during a mid-winter thaw, then I would suspect condensation in or around the fan duct as the source. The amount of water you collected would require condensation to form multiple times, continually freezing afterwards, to build up a significant layer of frost or ice. That often happens inside different types of fan ducts and is a common occurrence in our cold climate. It may also occur on the outside of a poorly insulated metal duct, inside a very cold attic, with similar leakage patterns when the frozen moisture melts. This may drip through the actual fan housing, or around it, with both types able to cause damage to the surrounding ceiling materials.

When water leaks into an attic from rain, it may drip into the building below in a different location than it enters. That is because water can cling to the underside of the roof sheathing, or any vertical or diagonal components inside that space. It may run down any of these spots and stop when it hits a more rigid impediment. In that situation, the leakage will usually be seen on the ceiling below the item which halts the progress of the moisture. The water may drip on to the ceiling below that location, or change direction and run down the side of the vertical member. Once enough water collects at that location on the attic side of the ceiling, it will find a hole, seam, or gap to leak through.

In your home, the conduit for the water leakage is likely the older exhaust fan ducting. The water may be entering from elsewhere and running down the sheathing until it hits the top of the duct. It will then change direction and flow down the side of that pipe. So, the area of leakage to repair on the roof should be above the top of that duct.

Alternatively, and even more likely, is that the vent hood for the duct termination on the roof is where the water is leaking in. It may only occur certain times, due to the rain’s intensity or wind direction. For example; if the bottom of the vent hood is facing west, a rainstorm with strong west winds may blow the flap in the hood up, allowing wind-driven rain to enter the duct. Rain on a day where the wind is blowing from any other direction may harmlessly flow around or over the vent hood, leaving your house dry. Conversely, if the water is leaking under a flashing at that vent hood, or some other roof protrusion, it may only get under the bottom when it is blown up the slope of the roof on a very windy day.

Sometimes diagnosing problems with roof leakage is fairly straightforward, if the water is leaking when it is raining. It should not be caused by condensation, and a very experienced roofer or general contractor may be required to try and duplicate specific weather conditions, often with a hose and sprayer, to locate the area of leakage and seal or replace the offending vent hood or flashing.

Ari Marantz is the owner of Trained Eye Home Inspection Ltd. and the past president of the Canadian Association of Home & Property Inspectors — Manitoba ( Questions can be emailed to the address below. Ari can be reached at 204-291-5358 or check out his website at

Ari Marantz
July 31


Renovation & Design

Dry soil around home can cause foundation issues

Question: I have heard a lot about watering foundations, given the dry conditions we are experiencing. From what I understand, the main reason for watering is to prevent the house from shifting. The shifting occurs due to dried out soil under the footings, which may cause the footings to drop, resulting in serious damage to the house.

My house is built on 16-inch diameter concrete piles, 25 feet deep. Is it just as crucial to water your foundation if your house was built on poured concrete piles? Can my house still shift if it’s on piles? I have tried finding an answer to this question on the internet but have been unsuccessful. Please help.

Thank you, Robert Fontaine.

Answer: You are correct that watering the soil around the foundation in these drought conditions is more important for homes built on footings, but can also help prevent other issues with your piled foundation, as well. Keeping the soil in your yard minimally saturated by watering may currently be a challenge, but should be done until we return to normal precipitation levels, even in your home built on piles.

The most serious issue that can often happen to a home, from a structural perspective, is for it to sink, or settle, over a short period of time. This will normally only occur if the soil underneath the foundation loses its structural integrity, in one or more areas. In the majority of homes built in our area, which are built on concrete footings, this may be caused by changes to the moisture level in the soil under these footings. If the expansive clay dries out too much, or becomes oversaturated, it will shrink or expand accordingly. In very dry weather, like the recent drought conditions, this can cause the clay soil to become powdery. In that state, it can lose much of its strength, which can allow the heavy foundation and house walls to sink. If that occurs in one area of a home and not others, it will cause some serious cracks and damage.

As I have written recently, and several times in past years, it is very important to keep the soil around the foundation hydrated, to prevent the deeper soil below the foundation from excessively drying out. You have a good understanding of the issue, as it is much less of a concern with a home like yours, which is built on deep concrete piers, commonly called piles. Because the piles go much deeper down in the soil, it is much less likely that the soil beneath those structures will be affected by weather-related soil conditions near the surface. The soil down that deep should be quite stable and always well saturated. However, it is not impossible that some settlement may still occur, because most concrete piers rely partially on friction with the soil surrounding them for support. If that soil dries excessively, it may pull away from the concrete, allowing some settlement due to excessive forces from above.

The above scenario is unlikely with your home, due to the size and depth of the concrete piers, but other issues may arise if the surface soil dries excessively. Initially, a sign of extreme dryness in this area is a gap between the foundation walls and the surrounding soil. This gap may not cause much concern, until it rains. Once significant precipitation returns, it may run down the house walls, easily entering this gap. If the damp-proofing on the foundation is worn out, the walls have moderate cracks, or the form ties have rusted through, seepage is likely. This may appear as a small leak at first, but could become serious leakage over time if the gap is not filled with returning higher soil moisture levels. Even though it may not cause the foundation walls to settle, excessive leakage through the foundation walls will be costly to repair, with major excavation still required.

Another possible side effect of very dry soil outside your foundation may be movement in the basement floor slab. Most foundation walls built on concrete piers have some type of void forms installed under them, to prevent the soil between the piles from moving after the concrete is poured. This cardboard or foam component is normally left in place, even after the basement floor slab concrete is poured. It then will help prevent the soil around the foundation falling into any gaps or voids created under the floor slab, over time. If the clay outside the foundation dries excessively, it may shrink unevenly in some locations, creating isolated gaps. If the same thing occurs underneath the perimeter of the basement floor, it can crack and sink. The void forms may deteriorate or crush over time, creating even more chance of this occurring. While it may not be otherwise structurally significant, a damaged basement floor slab can cause basement partition walls to move. In the worse case scenario, major movement in the soil beneath this concrete slab can cause shifting and damage to the plumbing drains and/or weeping tiles.

Adding moisture to dry soil around a house foundation, by watering with a garden hose or sprinkler, is definitely more important for a home built on footings than one on deep concrete piers. But that area should not be neglected in a piled home, either. Excessive drying of the soil due to lack of moisture can lead to future seepage, and/or basement floor slab movement issues, even in a house like yours. Regular watering is still required as long as the hot, dry summer weather continues.

Ari Marantz is the owner of Trained Eye Home Inspection Ltd. and the past president of the Canadian Association of Home & Property Inspectors — Manitoba ( Questions can be emailed to the address below. Ari can be reached at 204-291-5358 or check out his website at

Ari Marantz
July 24
